Garrett 880695-5001S Supercore G-Series G35-900, Trim 65

Garrett G35-900 supercore — a balanced core assembly (centre cartridge with compressor cover and back plate) for building or rebuilding G-Series turbochargers.

Designed with the latest Garrett G-Series technology, it delivers exceptional aerodynamic efficiency and durability in a compact package.

The forged milled compressor wheel, optimized using CFD analysis, ensures maximum airflow and performance, while the high-flow compressor housing integrates a plug-and-play speed sensor port for precise monitoring.

Dual ceramic ball bearings provide superior spool response and reliability, supported by water and oil cooling for thermal stability.

Specifications

• Frame: G35
• Bearing: ceramic ball bearing
• Rotation: standard
• Compressor wheel: 62 mm inducer, 76 mm exducer, 65 trim, 0.72 A/R
• Turbine wheel: 68 mm inducer, 62 mm exducer, 84 trim
• Turbine wheel material: MAR-M alloy
• Power: up to 900 HP
• Displacement: 2.0-5.5 L

Features

• CFD-optimized, forged milled compressor wheel
• High-flow compressor housing with integrated speed sensor port
• Standard rotation configuration
• Dual ceramic ball bearing cartridges for durability
• Includes -4AN oil restrictor fitting with 1 mm orifice
• Four large water jacket ports for increased cooling
• Turbine wheel constructed of MAR-M alloy rated to 1055 °C
• Oil-cooled bearing system
