DBA T2 Rotors – Advanced Braking Technology

Key Features & Technologies

T3 Slot Design (48 CNC Precision-Machined Slots)

• Tri-symmetrical curved slots reduce vibration harmonics and noise
• Provides a quieter, smoother, and more responsive brake pedal feel
• Increased out-gassing points for friction gases to escape
• Improves braking consistency and performance under load
• Universal slot design eliminates the need for left/right specific discs

Kangaroo Paw Ventilation System

• 144 diamond and tear-drop shaped pillars for increased surface area
• Enhances heat dissipation to reduce brake fade and improve effectiveness
• Extends the life of both pads and rotors, reducing wear and maintenance costs

XG150 High Carbon Alloyed Iron

• Higher thermal capacity for managing extreme heat during braking
• Reduces the risk of warping and cracking
• Improves overall rotor durability and performance

Thermal Stability Profiling (TSP)

• Special formulation compatible with DBA’s TSP process
• Minimizes rotor stress and prolongs service life under high-heat conditions

Thermographic Temperature Monitoring (TTM)

• Color-changing heat paint indicates peak temperature thresholds
• Permanent color changes help monitor rotor fatigue
• Assists drivers in determining rotor replacement and helps with warranty claims

Paint Protection on Non-Friction Areas

• Reduces corrosion and prevents unsightly rust
• Enhances visual appearance and adds product value

Technical information:

Diameter [mm]: 322
Disc Vent: Kangaroo Paw
Number of Holes: 5
Inner Diameter [mm]: 115
Minimum Thickness [mm]: 30
Thickness [mm]: 32
Height [mm]: 65
Pitch Circle [mm]: 144
Stage: Stage 2
ECE R90 number: E11*90R02/06*60514*00

Suitable for:

Front - TOYOTA/Landcruiser 70 series/4.2 D (HDJ78, HDJ79) 122 kW (2001-2007) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.2 D (HZJ76) 96 kW (2007-) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.2 D (HZJ78) 96 kW (1999-2007) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.2 D (HZJ79) 96 kW (1999-2007) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.2 D 4x4 (HZJ78) 123 kW (1990-2001) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.5 D (VDJ76) 151 kW (2007-2022) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.5 D (VDJ78) 151 kW (2007-2016) Brake Pads: DB1365, Front - TOYOTA/Landcruiser 70 series/4.5 D (VDJ79) 151 kW (2007-) Brake Pads: DB1365, Front - TOYOTA/Landcruiser FZJ105/4.5 (1998-2002) Brake Pads: DB1365, Front - TOYOTA/Landcruiser HZJ105/4.2 (1998-2007) Brake Pads: DB1365, Front - TOYOTA/Landcruiser VDJ/4.2 D (2006-) Brake Pads: DB1365,
